Single Phase |
Three Phase |
| Capacity |
1KVA-20KVA |
3KVA-200KVA |
| Input voltage range |
50V-270V, 170V to 270V |
260V to 470V, 300V to 470V (other range available on special order) |
| Output Voltage |
230/240V (Adjustable) |
400V to 415V (Adjustable) |
| Regulation |
_+ 1% or Better |
| Supply Frequency |
47Hz-53 Hz |
| Efficiency |
>98.6% |
| Effect of Load Power Factor |
NIL |
| Wave Form Distortion |
NIL |
| Rate of correction |
Better than 36V/Sec. in AN Type |
Better than 20V/Sec. in ONAN Type |
| Duty Cycle |
100% Continuous |
| Response Time |
Less than 10MS |
| Cooling |
AN/ONAN |
| Overload Capabilities |
up to 200% Momentarily |
| No Load Losses |
Less than 0.8% over Entire Range |
| Suitability |
Suitable for 3 Phase unbalanced/Balanced supply & unbalanced / Balanced Load |
| Mounting |
On wheels |
| Earthing |
Two Numbers of Earthings Terminals |
| Cable Termination Box |
Input / Output Connection |
| Ambient Temperature |
-10deg C to 50 deg C |
| Relative Humidity |
Upto 95% |
